产品型号：PFAWC-16Ca/24Ca/32Ca/48Ca
Product Model: PFAWC-16Ca/24Ca/32Ca/48Ca
适用管径：DN400/DN600/DN800/DN1200
Pipe Diameter Applicable: DN400/DN600/DN800/DN1200
性能特点：混合型产品；克服悬臂式焊机和普通焊机各自的缺点；适用于“管件+管子+管件”类管段的焊接；焊接效率提高100%以上；1台固定式带重载卡盘的焊接变位器；1台固定式分体式自动焊机；1台悬臂式焊接小车；3个支撑移动小车；2条18#轻轨；变位器和自动焊机设置在轨道两端；标配1或2台林肯Flextech650多功能焊接电源；采用QSPT打底焊接技术，进行TIG/MIG打底焊接；TIG/MIG/MAG/SAW填充、盖面焊接；铝合金线控盒操作。
Performance features: Integrated product; overcome the drawbacks of cantilever welding machine and regular welding machine; suitable for welding spool piece such as “fitting + pipe + fitting” ; the welding efficiency increased by more than 100%; one fixed type welding positioner with chuck; one Split Type Pipe Automatic Welding Machine; one cantilever welding trolley; three movable supporting trolleys; two 18# light track; the positioned and automatic welding machine installed at both ends of rail; standard configuration:one or two Lincoln Flextech650 multi-function welding power; TIG/MIG root welding with QSPT’s root welding technology; TIG/MIG/SAW fill-in and cap welding; operated with an aluminum alloy wire control box
