分体式管道自动焊机（普通型）

管道预制自动焊机（A8型）

产品型号：SPAWM-16Aa/24Aa/32Aa/48Aa

Model: SPAWM-16Aa/24Aa/32Aa/48Aa

适用管径：DN400/DN600/DN800/DN1200

Pipe Diameter Applicable: DN400/DN600/DN800/DN1200

性能特点：野外作业焊接工作站的标配焊机；较大提高物流效率；焊接驱动系统和立柱横臂系统分离；焊接驱动系统可沿轨道行走；标配林肯Flextech500多功能焊接电源；采用QSPT打底焊接技术，进行TIG/MIG打底焊接；TIG/MIG/MAG/SAW填充、盖面焊接;流线型焊接控制箱+铝合金线控盒操作；是管道预制生产线和自动焊接工作站的机型。

Performance Features: the standard welding machine for Workstation, significantly increasing conveying efficiency;separate weld driving system and column/boom system; welddriving system can move along the track;standard configuration: Lincoln Flextech500 multi-function welding power; TIG/MIG root welding with QSPT’s root welding technology; TIG/MIG/SAW fill-in and cap welding; operation through a streamlinewelding control cabinet + an aluminum alloy wire control box
