管道数控相贯线切割机

产品型号：PCPCM-16Ab/24Ab/32Ab/40Ab/48Ab/60Ab

Model: PCPCM-16Ab/24Ab/32Ab/40Ab/48Ab/60Ab

适用管径：DN400/DN600/DN800/DN1000/DN1200/DN1500

Pipe Diameter Applicable: DN400/DN600/DN800/DN1000/DN1200/DN1500

性能特点：配备较高性能数控相贯线切割软件；等离子或/和火焰切割；3-6轴控制轴数；原装进口工控机数控控制；松下伺服电机驱动；触摸屏人机界面；较高的定位和行走精度；手动3爪联动自定心；6个支撑小车；有效切割长度12米；标配海宝Powermax105；驱动系统标配为卡盘式（可选配滚床式）。

Performance Features: it is equipped with high performance CNC cutting software; Flame/Plasma Cutting; 3-6 Control Axises; Imported Original IPC numerical control with touch screen & man-machine interface; Drive by Panasonic Servo motor, High positioning and moving precision; manual 3 jaws linkage self centering chuck, 6 support trolleys; effective cutting length 12m; standard configuration of Hypertherm Powermax 105; chuck type driving system as standard (optional roller bench type).
