管道纵向物流输送系统(远距离型)

功能介绍 Function introduction

产品型号:PLRCS-16Ca/24Ca/32Ca/40Ca

Model: PLRCS-16Ca/24Ca/32Ca/40Ca

适用管径:DN400/DN600/DN800/DN1000

Pipe Diameter Applicable: DN400/DN600/DN800/DN1000

性能特点:将管子从切割坡口区输送至组对焊接区;V型聚氨脂辊轮;根据现场及运输条件分为多段制造;适用输送的管子长度:500mm(前段),1000mm(中段),2000mm(后段);变频无级调速;控制台PLC和手动控制(无线摇控选配);可分段启动和停止;到料自动停止与灯光报警。

Performance Features: Conveying the pipe from the cutting & beveling station to the fitting up and welding station; V Type PU roller; According to the site location and transport conditions are divided into multiple sections manufacture; applicable pipe length conveying: 500mm (front), 1000mm (middle), 2000mm (back), variable frequency stepless speed control, PLC Console and manual control (wireless remote control for option), can be started and stopped by section; automatically stop with the lighting alarm when materials are reached it.
