管道工厂预制详图设计软件

产品型号：CADWorx Plant

Model: CADWorx Plant

最新版本：2016版

Latest Version:  2016

性能特点：Intergraph鹰图软件产品；具有English、中文两种语言（自由切换）；需要AUTOCAD软件运行平台；建立管道等级库和管线数据库后，利用其绘图建模功能，对照设计院/工程公司原始单线图，绘制出3D单线图模型。设置现场口位置后，可生成安装所需的单线图和管道预制所需的管段图，并可导出管线、管段、焊缝、材料、长度等信息。亦可导出PCF文件，再利用SmartPlantSpoolgen来生成单线图和管段图。

Performance Feature: Intergraph Corporation producing; with English and Chinese two languages available (free to switch); the need for AUTOCAD software operating platform; After the Piping Classfication Database and the piping line database being created, take the advantage of its drawing and model-building function to plot the 3D ISOMetric drawing model with reference toOriginal ISOMetric drawing of Design Institute / Engineering Company. After the fieldweld joints position being confirmed, it can generates the ISOMetric drawing required for installation and the piping spool drawing required for prefabrication, and also export information of the piping line, piping spool, weld joint, requested materials and length etc... Also The PCF can be exported, And again taking advantage of the SmartPlantSpoolgen to generate the ISOMetric drawing and Piping Spool drawing.
