管道气动内对口器（长输管道）

管道气动内对口器（长输管道）Pneumatic Pipeline Internal Line-Up Clamp

产品型号：PPLUC-06Aa/08Aa/10Aa /12Aa/14Aa/16Aa/18Aa/22Aa/26Aa/32Aa/36Aa/40Aa/44Aa/48Aa

Model: PPLUC-06Aa/08Aa/10Aa /12Aa/14Aa/16Aa/18Aa/22Aa/26Aa/32Aa/36Aa/40Aa/44Aa/48Aa

适用管径：Φ154/203/254/305/305-355/355-406/406-457/508-559/610-660/711-813/813-914/914-1016/1067-1118/1168-1219

Pipe Diameter Applicable: Φ154/203/254/305/305-355/355-406/406-457

/508-559/610-660/711-813/813-914/914-1016/1067-1118/1168-1219

性能特点：驱动系统的单侧单轮（18A-36A）或单侧双轮（40A-56A）行走驱动、刹车系统的单侧单刹（18A-36A）或三侧双刹（40A-56A）到位刹车、两组气缸多个压块账紧在焊口两侧管子内、适用于长输管道的管管组对

Performance features: one side single wheel (19A-36A) or one side two wheels (40A-56A) traveldriving of driven system; one side single brake (18A-36A) or three-side two-brake (40A-56A) positioning brake system; two sets of cylinders and multiple pressing blocks are compressed against the inside wall at two sides of weld junction; applicable for pipeline fitting up.

Performance features: The expansion component mounted inside the pipe; automatic and rapid centering with hydraulic cylinder; pipe end beveling with floating tool holder and numerical control blade; cold cutting without coolant; suitable for beveling before  welding by Orbital Pipeline Automatic Welding Machine.
